Battery Type | Capacity AH | L MM |
W MM |
H MM |
Nominal Weight without charge |
Electrolyle Volume(ltr.) | Charging Current | Battery Layout |
---|---|---|---|---|---|---|---|---|
34B 20R
|
32 | 195 | 125 | 225 | 8.7 | 2.6 | 2.5 |
![]() |
38B 20R |
35 | 195 | 125 | 225 | 9.7 | 2.5 | 3.0 |
![]() |
38B 20L |
35 | 195 | 125 | 255 | 9.7 | 2.5 | 5.0 |
![]() |
12Volt - 9Plate |
50 | 260 | 170 | 218 | 15 | 4.5 | 6.0 |
![]() |
12Volt - 10Plate |
60 | 260 | 170 | 218 | 17 | 4.3 | 6.0 |
![]() |
12Volt - 11Plate |
70 | 305 | 170 | 225 | 18 | 5.0 | 6.0 |
![]() |
12Volt - 13Plate |
80 | 305 | 170 | 225 | 21 | 4.8 | 6.0 |
![]() |
12Volt - 13Plate |
88 | 410 | 172 | 235 | 21.5 | 5.5 | 6.0 |
![]() |
12Volt - 15Plate |
100 | 410 | 172 | 235 | 24 | 5.3 | 6.5 |
![]() |
Technical Specification of Solar LCV/HCV
Battery Type | Capacity AH | L MM |
W MM |
H MM |
Nominal Weight without charge |
Electrolyle Volume(ltr.) | Charging Current | Battery Layout |
---|---|---|---|---|---|---|---|---|
12Volt - 11Plate
|
70 | 305 | 170 | 225 | 18 | 5 | 6.0 | ![]() |
12Volt - 13Plate |
80 | 305 | 170 | 225 | 21 | 4.8 | 6.0 |
![]() |
12Volt - 13Plate |
88 | 410 | 172 | 235 | 21.5 | 5.5 | 6.0 |
![]() |
12Volt - 15Plate |
100 | 410 | 172 | 235 | 24 | 7 | 6.0 |
![]() |
12Volt - 17Plate |
120 | 507 | 180 | 235 | 28 | 9 | 7 |
![]() |
12Volt - 19Plate |
135 | 507 | 180 | 235 | 31 | 8 | 7 |
![]() |
12Volt - 21Plate |
150 | 505 | 220 | 255 | 34 | 11 | 9 |
![]() |
12Volt - 25Plate |
180 | 510 | 278 | 240 | 40 | 17 | 11 | ![]() |
DIN SERIES
Battery Type | Capacity AH | L MM |
W MM |
H MM |
Nominal Weight without charge |
Electrolyle Volume(ltr.) | Charging Current | Battery Layout |
---|---|---|---|---|---|---|---|---|
DIN 44L
|
44 | 210 | 175 | 190 | 11 | 3.0 | 3.0 | ![]() |
DIN 44R |
44 | 210 | 175 | 190 | 11 | 3.0 | 3.0 |
![]() |
DIN 50L |
50 | 210 | 175 | 190 | 11.5 | 2.9 | 3.5 |
![]() |
DIN 50R |
50 | 210 | 175 | 190 | 11.5 | 2.9 | 3.5 |
![]() |
DIN 55L |
55 | 243 | 175 | 190 | 12.5 | 3.7 | 3.5 |
![]() |
DIN 60L |
60 | 243 | 175 | 190 | 13 | 3.5 | 4.0 |
![]() |
DIN 60R |
60 | 243 | 175 | 190 | 13 | 3.5 | 4.0 |
![]() |
DIN 66L |
66 | 278 | 175 | 190 | 14.5 | 4.2 | 4.5 | ![]() |
DIN 74L |
74 | 278 | 175 | 190 | 15.7 | 4.0 | 5.0 | ![]() |
